XCMG Official Qy50ka 50 Ton Hydraulic Lift Truck Crane Price
XCMG official QY50KA 50 ton hydraulic lift truck crane price
XCMG QY50KA truck crane's structure is compact, the industry operating performance is the highest. Lifting performance and driving performance of a comprehensive upgrade, leading competitors. Dual-pump confluence technology, operating efficiency of a comprehensive lead.

Advantages and highlights:
1. Leading lifting and driving performances
Five section U-type booms. The boom length is 11.4m-43.5m with strong lifting performance, leading 5%-10% ahead of products with the same tonnages in the same industry.
High-power engine with good dynamic performance, strong gradeability and superior trafficability. The maximum gradeability and maximum travel speed respectively are 42% and 85km/h.
2. Reliability of heat dissipation, electrical system etc. has been improved with safer operation and driving
Waterproof connector clip is equipped with rubber sheath inside with excellent water impervious and level of protection reaches to IP65.
The air-conditioning condenser is separately installed, the heat-sinking capability is sharply improved and the environment temperature reached to more than 45.
3. Mature and reliable double-pump confluence technique, maintaining the advantages of efficient operation
The double-pump confluence technique is adopted in raising and falling of winch, extending and retracting of lazy boom and luffing, leading ahead of luffing and extending and retracting operations.
4. Air-aid shift gears and 45% of shifting force is reduced
The boost system will work only by stepping on the clutch that effectively avoids gearbox damaging gears when shifting. Compared with the same industry, 100mm distance of shift gears and 45% of shifting force are respectively reduced.
Product Paramenters
DescriptionUnitParameter value
Overall lengthmm13930
Overall widthmm2780
Overall Heightmm3630
Axle base1st ,2nd axlemm1470
2nd ,3rd axle4300
3rd ,4th axle1350
Wheel Basemm2304+2075
Front overhang/rear overhangmm2389/2064or 2376/2064
Front extension/rear extensionmm2131/226 or 2144/226
Total vehicle mass in travel configurationkg42200
Axle loadFront axlekg16200
Rear axle26000
Engine Model WD615.338
Engine rated powerkw/(r/min)276/2200
Engine rated torqueN.m/(r/min)1500/1300-1600
Max. travel speedkm/h85
Min. steady travel speedkm/h2~3
Min. turning diameterm24
Min. ground clearancemm327
Max. grade ability%42
Approach angle°19
Departure angle°15
Braking distance (at 30 km/h, full load )m≤10
Oil consumption per 100kmL40
Exterior noise level during acceleration travelingdB (A)≤88
Noise level at seated positiondB (A)≤90
